Class/Structure: Cubic diamond, Fd3m
Lattice Materials has a number of documents collected here for your convenience. We have whitepapers, SDS, material properties, and packaging details available.
If you do not see what you are looking for, contact us and we will be happy to get it to you.
Review our standard packaging and request custom packaging for your optics or other parts.
Atomic Number: 14
Group: 14 or IV A
Atomic Weight: 28.0855
Period: 3
Melting Point: 1414 °C / 2577.2 °F
Density: 2.3290 g/cm3
Thermal Expansion: 2.6 µm•m−1•K−1 (at 25 °C)
Thermal Conductivity: 149 W•m−1•K−1
Electrical Resistivity: at 20 °C: 10 Ω•m3
Band Gap: 1.12 eV (at 300 K)
Young’s Modulus: 130-188 GPa
Shear Modulus: 51-80 GPa
Bulk Modulus: 97.6 GPa
Poisson Ratio: 0.064 – 0.28
Mohs Hardness: 7
Knoop Hardness: 1150
CAS Number: 7440-21-3
Transmission Range: 1.2 to 15 μm, best from 3-5μm
Refractive Index: 3.4223 @ 5 μm
Reflection Loss: 46.2% at 5 μm (2 surfaces)
Absorption Coefficient: 0.01 cm-1 at 3 μm
dn/dT: 160 x 10-6 /°C (3)
dn/dμ: 0 : 10.4 μm
Elastic Coefficients: C11=167; C12=65; C44=80 (4)
Apparent Elastic Limit: 124.1MPa (18000 psi)
Solubility: Insoluble in Water
Class/Structure: Cubic diamond, Fd3m
Atomic Number: 32
Group: 14 or IV A
Atomic Weight: 72.64
Period: 4
Melting Point: 938.25 °C / 1720.85 °F
Density: 5.3234 g/cm3
Thermal Expansion: 6.0 µm•m−1•K−1
Thermal Conductivity: 60.2 W•m−1•K−1
Electrical Resistivity: 1 Ω•m at 20°C
Band Gap: 0.67 eV (at 300 K)
Young’s Modulus: 103 GPa
Shear Modulus: 41 GPa
Bulk Modulus: 75 GPa
Poisson Ratio: 0.26
Mohs Hardness: 6.0
Knoop Hardness: 780
CAS Number: 7440-56-4
Transmission Range: 1.8 to 23 μm, best from 8-12μm
Refractive Index: 4.0026 at 11 μm (1)(2)
Reflection Loss: 53% at 11 μm (Two surfaces)
Absorption Coefficient: <0.027 cm-1 @ 10.6 μm
dn/dT: 396 x 10-6 /°C (2)(6)
dn/dμ: Almost constant
Elastic Coefficients: C11=129; C12=48.3; C44=67.1 (5)
Apparent Elastic Limit: 89.6 MPa (13000 psi)
Solubility: Insoluble in water
Class/Structure: Cubic Diamond, Fd3m
